Designed Specifically For Drag Racing
For Pro Series & Pro II Steel Brake Kits
• All H/D Front Kits
• Rear Kits Using DTC-30 Semi Metallic Pads
For Pro II Stainless with Billet Calipers – B1950
Four Piston Aluminum Directional Calipers – B5002 / B5004
• Aluminum bodies drastically reduce weight
• 1.625″ & 1.750″ pistons vary pressure decreasing pad taper
• Stainless steel pistons are corrosion resistant
• Anti-rattle clips reduce brake pad vibration and noise
Bolt Kit
• Four 3/8″-24 x 1.125″ grade 8 bolts
• Four 3/8″ ID .125″ thick washers
• Sixteen 3/8″ ID .025″ thick stainless steel alignment shims
DTC-30 Semi Metallic Brake Pads – B5010
• Provides the best starting-line cold holding power
• Only material suitable for use in front steel applications
• Rear application in vehicles going 150 MPH or less in the 1/4 mile
Brake Hoses and Lines Are Not Included
Calipers are tapped 1/8″ NPT and supplied with male 3 AN fittings
Use Teflon® tape or liquid on the pipe threads of the fitting
Leave a few threads from the tip uncoated
This will avoid depositing material inside the caliper
Torque fitting to 25 ft lbs
For Rear Applications With Other Pads
DRM-35 metallic pads – B1855
DRM-40 metallic pads – B1853
