Strange Brake Adapter Kit                                                                           Adapts 94-04 Mustang GT Brakes to Late Big Ford Ends                             For Use with Tapered Axle Bearings

////

Strange Brake Adapter Kit                                                                           Adapts 94-04 Mustang GT Brakes to Late Big Ford Ends                             For Use with Tapered Axle Bearings

Strange Brake Adapter Kit                                                                           Adapts 94-04 Mustang GT Brakes to Late Big Ford Ends                             For Use with Tapered Axle Bearings

$198.00

Part Number: B1706MC

Application
Allows 94-04 GT brakes to be used with Late Big Ford Ends

1994-2004 Mustang brake offset is 3.250″
Typical brake offset for Late Big Ford ends is 2.500″
These brackets move the calipers inboard .750″ to make up the difference

Kit Includes
Billet aluminum caliper mounts
Caliper washers
Housing end stud kit

Additional Parts Required

Axles
Axles with 2.500″ brake offset & 2.780″ brake register
Timken® tapered axle bearings

Note
Downloaded instructions before ordering axles

Brakes
94-04 Mustang GT brakes- Less caliper mounts

Housing Ends
Strange H1137 housing ends or equivalent

Notes for ABS
Axle flanges will need an access hole
Requires custom reluctor rings – A1094EM
Reuse OEM sensors

Parts List and Installation Guide

Description

Mustang Brake Adapter Kit Adapts 1994-2004 GT Brakes To Late Big Ford Ends

Additional information

Weight 3.70 lbs
