Application
1984-1996 Corvette
Standard Gears are the perfect choice for replacement of OEM gear sets
Providing long service life in Street, Street / Track, & Oval track vehicles
These gears can also be used in some Drag Race cars depending on weight & power
If tooth breakage occurs, a larger rear end will become necessary
Designed For 3.07 And Numerically Higher Carrier
Machined From 8620 Forged Steel
Heat Treated to Maximize Gear Life
Matched Ring & Pinion Set
Ring Gear
– 7.75″ OD
– Tooth count 46
– 10 bolt holes
– 3/8″-24 RH threads
Pinion
– 26 spline shaft
– Tooth count 13
– 7/8″-16 RH threads
Unsure about your application?
Please contact a Strange Sales Associate to discuss your vehicle
