12 Bolt Housing With F-Body Mounts - No Housing Ends


Part Number: H12FM

1982-2002 Camaro / Trans Am

12 bolt housing
Includes tubes & F-Body mounts – No ends

Perfect base for creating Pro Touring floater housing

Information Required
Tube to tube width

Nodular iron center – H1106A
– Chrome moly main caps
– Integral torque arm provision
– Three channel sensor hole
– Accepts 12 bolt internal components

3″ x .250″ Wall Tubes – H1139
– Seamless DOM mild steel

Coil Spring & Lower Control Arm Mounts
– Strange heavy duty
– Multiple lower control arm mounting holes
– Provides wide range of traction adjustment

Choice Of Tube To Tube Width
– Factory width
– Custom width at no additional charge

Professionally Welded
– Jig welded to ensure proper alignment
– Tubes plug & 360° welded to casting
– Eliminates tube rotation issues

Specify if using 3 channel, 4 channel, or no ABS
3 channel ABS requires Strange sensor & o-ring

Related Components
3 channel ABS sensor………….. H1106S
Sensor o-ring…………………….. S5000SAB
Pro Touring floater kit………….. F5010

This product is only available from an Authorized Strange Dealer or Factory Direct Call - 800-646-6718 or Email Us


12 bolt F-Body housing / with F-Body mounts (no ends)
