Strange Billet 4 Piston Red Caliper Kit
With High Temp Metallic Pads


Part Number: B1953-RD

Designed Specifically For Drag Racing

Same Calipers Supplied in Pro II Stainless Steel Brake Kits
Can be used in most other Strange brake kits


Four Piston Billet Red CalipersB1900-RD
• Billet aluminum bodies are extremely ridged & reduce weight
• Pistons are machined from billet stainless steel
• Much stiffer than common stamped stainless pistons
• Highly resistant to deflection resulting in a very firm pedal
• All pistons are 1.750″ to provide maximum clamping force
• Red powder coat finish

Bolt Kit
• Four 3/8″-24 x 1.127″ NAS bolts
• Four 3/8″ ID .125″ thick washers
• Sixteen 3/8″ ID .025″ thick stainless steel alignment shims

High Temp Metallic Brake PadsB5022
• Provides the highest resistance to brake fade
• Recommended for vehicles going over 150 MPH in the 1/4 mile
• Pad residue on rotor surface greatly reduced over hard pads

Brake Hoses and Lines Are Not Included
Calipers are tapped 1/8″ NPT and supplied with male 3 AN fittings

Use Teflon® tape or liquid on the pipe threads of the fitting
Leave a few threads from the tip uncoated
This will avoid depositing material inside the caliper
Torque fitting to 25 ft lbs

Caliper Kits With Other Pads
Soft metallic pads – B1950-RD
Hard metallic pads – B1955-RD


Strange Red Billet Four Piston Caliper Kit – High Temp Pads
